#CISCO 2950 SWITCH CONFIGURATION COMMANDS PC#
Using a separate terminal session (not using minicom) on the PC and try to ping the other devices in the network. Now, type: Switch> show interfaces and record the first two lines of output here: Type: Switch> show interface status Fill in the table for the 2 lines that describe ports Fa0/1 and Fa0/12: Port Name Status Vlan Duplex Fa0/1 Take a look at the available interfaces now that the switch has been reset to factory defaults. We are going to avoid the configuration “wizard”. After approximately 2 minutes (and a lot of messages) the router will ask the following: Would you like to enter the initial configuration dialog? : Answer this question by typing “n” or “no”. This is why you are using minicom in one of the terminal sessions to connect to the switch You should note that the minicom session is reporting some activity on the switch as it reboots.
#CISCO 2950 SWITCH CONFIGURATION COMMANDS SERIAL#
At this point, the ONLY way to communicate with the switch is through its console port, which is connected to the PC‟s serial port. We‟ll confirm this later by attempting to ping the other devices. Thus, currently your PC can not use Ethernet to contact any other device. (Deletes startup configuration stored in flash memory.) (Reboot switch with factory settings)Īt this point, all of the switch interfaces will be inoperable, including the one to which your PC‟s Ethernet cable is attached. Now, let‟s clear all current configurations and reset the switch to factory defaults SwitchA# erase start SwitchA# reload We‟re going to clear all of the settings and configure the switch from scratch anyway. If the configuration settings for your switch are not correct, don‟t worry. You should also refer to the “Logical Configuration” diagram so that you may see how the equipment you are using fits into the entire configuration. You may refer to Appendix A to confirm that the configuration is currently as it should be. Type the following command at the SwitchX# prompt and fill in the blanks in the table that follows. Before we clear the switch‟s settings (and lose network access), let‟s take a look at the current configuration. You should note the prompt change from SwitchX> to SwitchX# SwitchX> enable Password: enable-secret-password SwitchA#Į. Almost all IOS commands require privileged EXEC mode access.
In a terminal session, use minicom to initiate the connection to the switch via the serial cable. In the instructions that follow SwitchX refers to the switch to which you are connected - either SwitchA, SwitchB or SwitchC. If so, move it to the console port on the switch. The serial cable may be connected to the console port on the router. Ensure that the serial cable from your computer is connected to the console port on your switch. Unless another team is working on another set of equipment and has altered their configuration, you should be able to ping the following devices: PC-A PC-B PC-Cī. Using a terminal session on the PC, try to ping all of the devices on the network. Before we alter the switch configuration, let‟s check current connectivity. Since you will need two sessions, repeat this step, if necessary. Enter the command: cd /home/comp311 so that all files you might generate will be saved in the comp311 folder. After a few seconds, a terminal window should appear. If two sessions are not already running, click on the Terminal icon that you should find on the desktop. You will need two terminal sessions on your desktop for this exercise.
Indicate by circling which hardware set your team used: PC-A with RouterA & SwitchA Your team will use one of 3 hardware sets (a PC, a router, & a switch). Catalyst 2950 Switch Configuration Team Members: _ Teams will consist of 2-3 students each.
